No.1 Pipe Bending Machine Manufacturer, Supplier in Ahmedabad, India
A Pipe Bending Machine is primarily used for shaping the pipes and tubes manufactured with different metals or alloys. The pipe bending machine can be used either for a small pipe or a large one. The pressure of the Pipe bending machine is suitable for quick usage or a heavy one without high power. The usage of a bending machine is user-friendly for bending hard metal such as steel, aluminum, or other than the bending machine is a stop solution.
CNC Pipe Bending Machine
| Categories | Motorized Pipe Bending Machines |
|---|---|
| Brand | BendTech Engineers (Brand Name:- BTE) |
| Model | BTE-MDBM |
| Condition | New |
| Raw Material | Pipe |
| Material / Metal Processed | carbon steel, stainless steel, copper, aluminium, galvanized, etc. |
| Power | Electrical |
| Automation | Manual |
| After-sales Service Provided | Engineers available to service machinery overseas |
| Operation | By Push button Switches |
| FOB port | Mundra Port(Gujarat) , Nahva sheva Port(Maharastra) |
Technical Specification-Pipe Bending Machine
| Sr No. | Details | Specification | Specification |
| 1 | Model No. | BTE-2CNC | BTE-3CNC |
| 2. | Pipe Size Max | 50 mm | 75 mm |
| 3. | Pipe Size Min | 10 mm | 10 mm |
| 4. | Pipe Wall Thickness | Up to 3.5 mm | Up to 3.5 mm |
| 5. | Pipe Material | S.S., M.S, Al, Cu | S.S., M.S, Al, Cu |
| 6. | Bending Direction | Clockwise | Clockwise |
| 7. | Max. Bending Radius | 200 mm | 200 mm |
| 8. | Mini Bending Radius | 1.5 D | 1.5 D |
| 9. | Max Bending Angle | 1800 | 1800 |
| 10. | Bending Accuracy | ±1.5 % | ±1.5 % |
| 11. | Mandrel Length | (adjustable as per application) | (adjustable as per application) |
| 12. | Max Hydraulic Pressure | 150 bar | 150 bar |
| 13. | Operating Voltage | 415v, 50Hz,3ph | 415v, 50Hz,3ph |
| 14. | Motor Power | 5Hp | 7.5Hp |
| 15. | Hydraulic Valves | Yes (Standard Make) | Yes (Standard Make) |
| 16. | Motor | Yes (Standard Make) | Yes (Standard Make) |
| 17. | Pipe Clamping and Dis-clamping system | Automatic | Automatic |
| 18. | Electronic Parts | Schneider | Schneider |
| 19. | Control Panel with PLC | 7 inch color LED Display | 7 inch color LED Display |
| 20. | More than 6 angle in single Program | ||
| 21. | Rotating servo motor | 1KW | 1KW |
| 22. | Reciprocating Servo | 1 KW | 1 KW |
| 23. | One Die Set with Mandrel | BTE | BTE |
